Haco Atlantic HTL-GS6022TG Tube Laser
WA -
-
-
-
+2
Haco Atlantic HTL-GS6022TG Tube Laser : $225,000 AUD ($247,500 Inc. GST)
Atlantic - Fibre Tube Laser
Model HTL-GS6022TG
Laser Type Fiber Laser IPG
Laser Power 2000W
Manual loading machine (Option Bundle Load)
Tube Cutting Length Range Max 6000 mm
Maximum chuck load capacity 120 kg
Maximum length of laying-off 3000mm
X-axis travel 7000 mm
Y-axis travel 500 mm
Z-axis travel 400 mm
A-axis travel Infinite rotating
W-axis travel Infinite rotating
Round Tube Cutting Diameter Range 20mm~220mm (other sizes available)
Square Tube Cutting Range 20mm x 20mm ~160mm x 160mm
Other available tube: Rectangular tube, round tube, OB tube, D-tube, triangle tube, elliptical tube, equal-diameter shaped tube and other standard tube type
Working Voltage 380 V/50Hz
Power Consumption 24.33 KW
Automatic clamp tube Yes
Follow-up support Yes
Machine Dimension 10380*2000*2500mm
Gross weight 6 tons
Options available
Front Support $17500.00 + gst
auto loading device $102000.00 + gst
